Cisco CATALYST 2960 Command Reference Guide

2-669
Catalyst 2960 Switch Command Reference
OL-8604-03
Chapter 2 Catalyst 3750 Switch Cisco IOS Commands
spanning-tree mst port-priority
spanning-tree mst port-priority
Use the spanning-tree mst port-priority interface configuration command to configure an interface
priority. If a loop occurs, the Multiple Spanning Tree Protocol (MSTP) can find the interface to put in
the forwarding state. Use the no form of this command to return to the default setting.
spanning-tree mst instance-id port-priority priority
no spanning-tree mst instance-id port-priority
Syntax Description
Defaults The default is 128.
Command Modes Interface configuration
Command History
Usage Guidelines You can assign higher priority values (lower numerical values) to interfaces that you want selected first
and lower priority values (higher numerical values) that you want selected last. If all interfaces have the
same priority value, the multiple spanning tree (MST) puts the interface with the lowest interface
number in the forwarding state and blocks other interfaces.
instance-id Range of spanning-tree instances. You can specify a single instance, a range of
instances separated by a hyphen, or a series of instances separated by a comma. The
range is 0 to 4094.
priority The range is 0 to 240 in increments of 16. Valid priority values are 0, 16, 32, 48, 64,
80, 96, 112, 128, 144, 160, 176, 192, 208, 224, and 240. All other values are
rejected. The lower the number, the higher the priority.
Release Modification
12.2(25)FX This command was introduced.
12.2(25)SED The instance-id range changed to 1 to 4094.

Cisco CATALYST 2960 Specifications

General

Manageable	Yes
Stacking	No
Model	Catalyst 2960 Series Switches
Power over Ethernet (PoE)	Available on some models (IEEE 802.3af)
VLANs	255 active VLANs
Features	QoS
Operating Temperature	32 to 113°F (0 to 45°C)
Relative Humidity	10% to 85% non-condensing
Power Consumption	Varies by model (30W to 400W)
