4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4-65
Similarly, an error message will be displayed if the selected settings result in a
PID collision, which indicates that either the selected PID mapping resulted in
the selection of a PID which is being used for another service.
6. Go to Setup: Outputs, TS Out: ASI, and set the Output Mode to Full DPM
Control. Also, if necessary set the Descramble Mode according to whether the
program is to be Scrambled or Descrambled for downstream monitoring.
7. On the same menu, set the following parameters:
8. Set the table parameters as follows:
Parameter Description
Map Mode Svc ID & PID
Duplic Mode Pkt Copy
Unref Drop
PSI Options Ctl by Table
PSI Rate Any
Svc ID Any
Parameter Description
PAT Regen
CAT Regen
PMT Regen
TSDT Drop
NIT Regen or Drop
NITO Drop
SDT Regen
SDTO Drop
BAT Drop
EIT Drop
TDT Pass
RST Pass
