4023074 Rev B Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4-35
Setup Menu: IP, Continued
IP
Port ID
Description: Displays the ID for the Ethernet port.
Parameters: 1 to 3. The default is 1.
Description
Description: Sets the description or name for the Ethernet port.
Parameters: Up to 20 alphanumeric characters in length.
V4/V6
Description: Displays the TCP IP communication protocol version supported on
the Ethernet port.
Parameters: This value is not editable. Only V4 is currently supported.
IP Address
Description: Sets the IP Address for its participation in a Network environment.
Parameters: Up to 12 digits in length.
Mask
Description: Sets the Subnet Mask for its participation in a Network
environment.
Parameters: Up to 2 digits in length.
Gateway
Description: Sets the Network Gateway Address on the Network, used to expose
the transcoder to a WAN.
Parameters: The IP Address/Mask and Gateway Address should be changed
together, i.e., as a group. The following table shows the most
commonly used Subnet mask values to enter for a chosen IP
address mask, which will depend on the size of your network.
MAC Address
Description: Displays the MAC address of the transcoder. It is set at the factory
and is a read-only value.
Parameters: N/A.
Mask Subnet Mask
8 255.0.0.0
16 255.255.0.0
24 255.255.255.0
