4-40 Model D9858 Advanced Receiver Transcoder Installation and Operation Guide 4023074 Rev B
Setup Menu: Services: Video, Continued
Stream TV A/R Conversion Act Conv Description Image
4:3 16:9 4:3 P/B 4:3 P/B 4:3 picture is centered in a
pillar-style box.
4:3 16:9 14:9 14:9 Compromises some up-
sampling. Some black bars
and cropping are visible.
4:3 16:9 16:9 F/W 16:9 F/W Vertically up-samples the
centre of the 4:3 picture and
crops the top and bottom of
the screen.
16:9 16:9 None None Normal
16:9 16:9 Auto None No conversion. Normal
picture.
16:9 16:9 4:3 L/B None Conversion is not possible.
Normal picture.
16:9 16:9 4:3 F/H None Conversion is not possible.
Normal picture.
16:9 16:9 4:3 P/B None Conversion is not possible.
Normal picture.
16:9 16:9 14:9 None Conversion is not possible.
Normal picture.
16:9 16:9 16:9 F/W None Conversion is not possible.
Normal picture.
16:9 4:3 None None Picture appears tall and thin.
4:3 PB
14:9
16:9 FH
16:9
16:9 Compressed
To Next Page
