Pin(s)
Signal Name
Definition
5, 6
External Radio 2 AUD
Hi/Lo
These pins provide an audio output to the audio system from
External Radio 2. Assignment of a transceiver to External Radio
2 is a programmable option, default is to the audio
management unit. This output is capable of adjustment from
2.5Vrms ±0.25 Vrms (10mW) to 7.75 Vrms ±0.25 Vrms
(100mW) into a 600 Ω load (except as noted)
7, 8
Audio 3 Out Hi/Lo
These pins provide an audio output to the audio system from
Transceiver 3. Assignment of a transceiver to Audio 3 is a
programmable option, default is to the transceiver in slot 3.
This output is capable of adjustment from 2.5Vrms ±0.25 Vrms
(10mW) to 7.75 Vrms ±0.25 Vrms (100mW) into a 600 Ω load
(except as noted)
9, 10
External Radio 1 AUD
Hi/Lo
These pins provide an audio output to the audio system from
External Radio 1. Assignment of a transceiver to External Radio
1 is a programmable option, default is to the audio
management unit. This output is capable of adjustment from
2.5Vrms ±0.25 Vrms (10mW) to 7.75 Vrms ±0.25 Vrms
(100mW) into a 600 Ω load (except as noted)
11
Audio 3 PTT IN_N
Grounding this pin enables Audio 3 Push-To-Talk function.
There is a Stuck MIC timer of 120s in order to timeout
continuous transmission on COM channels.
12
RESERVED
Reserved for factory use only.
13
Day/Night_N
A ground on this pin invokes nighttime lighting mode to reduce
the brightness of the panel lighting. Lighting levels are
configurable (PMR only)
14
PS Enable_N
Grounding this pin enables the power supply in remote radios
being controlled by the RT-7000 PMR
15, 16
Antenna Control 1 RX
LO/HI
These pins accept an RS-422 feedback signal from the optional
tunable antenna 1.
17, 18
Antenna Control 3 RX
LO/HI
These pins accept an RS-422 control signal to the Antenna
Tuner for Antenna Port 3.
19, 20
Antenna Control 3 TX
HI/LO
These pins provide an RS-422 data signal to the Antenna
Tuner for Antenna Port 3
21, 22
Jack 2 In Hi/Lo
These pins accept an audio input for Jack2 (default hand held
radio #1) with the following characteristics: Input Impedance:
1000 Ω ± 10% maximum. : Circuitry type: Differential. : Input
Gain Selectable: 10 mW. : 25mW and 100mW. : Rated input:
7.75 Vrms ±0.25 Vrms (100mW) nominal from 600 Ω ±10%
audio source
23, 24
Jack 1 In Hi/Lo
These pins accept an audio input for Jack1 (default hand held
radio #1) with the following characteristics: Input Impedance:
1000 Ω ± 10% maximum. : Circuitry type: Differential. : Input
Gain Selectable: 10 mW, 25mW, 100mW. : Rated input: 7.75
Vrms ±0.25 Vrms (100mW) nominal from 600 Ω ±10% audio
source.
25, 26
Mic 3 In Hi/Lo
These pins accept an audio input for Audio 3 (default radio in
slot 3) with the following characteristics: Input Impedance:
1000 Ω ± 10% maximum. : Input Impedance: 1000 Ω ± 10%
maximum. : Circuitry type: Differential. : Input Gain Selectable:
10 mW, 25mW, 100mW. : Rated input: 7.75 Vrms ±0.25 Vrms
(100mW) nominal from 600 Ω ±10% audio source
