COBHAM RT-7000 PMR User Manual

150-071724 Rev N
This document contains proprietary information,
see proprietary statement on first page.
Page 82 of 138
Pin(s)
Signal Name
Definition
27, 28
Mic 2 In Hi/Lo
These pins accept an audio input for Audio 2 (default radio in
slot 2) with the following characteristics: Input Impedance:
1000 Ω ± 10% maximum. : Input Impedance: 1000 Ω ± 10%
maximum. : Circuitry type: Differential. : Input Gain Selectable:
10 mW, 25mW, 100mW. : Rated input: 7.75 Vrms ±0.25 Vrms
(100mW) nominal from 600 Ω ±10% audio source
29, 30
External Radio 2 MIC
Hi/Lo
These pins accept an audio input for External Radio 2 (default
AMU) with the following characteristics: Input Impedance:
1000 Ω ± 10% maximum. : Input Impedance: 1000 Ω ± 10%
maximum. : Circuitry type: Differential. : Input Gain Selectable:
10 mW, 25mW, 100mW. : Rated input: 7.75 Vrms ±0.25 Vrms
(100mW) nominal from 600 Ω ±10% audio source
31
Reserved
Reserved
32
Audio 2 PTT IN_N
Grounding this pin enables Audio 2 Push-To-Talk function.
There is a Stuck MIC timer of 120s in order to timeout
continuous transmission on COM channels.
33
Audio 1 PTT IN_N
Grounding this pin enables Audio 1 Push-To-Talk function.
There is a Stuck MIC timer of 120s in order to timeout
continuous transmission on COM channels.
34
External Radio 2 PTT_N
Grounding this pin enables External Radio 2 Push-To-Talk
function. There is a Stuck MIC timer of 120s in order to
timeout continuous transmission on COM channels.
35
External Radio 1 PTT
IN_N
Grounding this pin enables External Radio 1 Push-To-Talk
function. There is a Stuck MIC timer of 120s in order to
timeout continuous transmission on COM channels.
36, 37
Remote Radio Control TX
HI/LO
These pins provide an RS-422 data signal to the RCDU or third
party control head.
38, 39
Antenna Control 1 TX
LO/HI
These pins provide an RS-422 control signal to the optional
tunable antenna 1.
40, 41
Jack 1 Out Hi/Lo
These pins provide an audio output from the audio system to
External Radio 1. This output is capable of adjustment from
2.5Vrms ±0.25 Vrms (10mW) to 7.75 Vrms ±0.25 Vrms
(100mW) into a 600 Ω load (except as noted)
42, 43
External Radio 1 MIC
Hi/Lo
These pins accept an audio input for External Radio 1 (default
AMU) with the following characteristics: Input Impedance:
1000 Ω ± 10% maximum. : Input Impedance: 1000 Ω ± 10%
maximum. : Circuitry type: Differential. : Input Gain Selectable:
10 mW, 25mW, 100mW. : Rated input: 7.75 Vrms ±0.25 Vrms
(100mW) nominal from 600 Ω ±10% audio source
44, 45
Jack 2 Out Hi/Lo
These pins provide an audio output from the audio system to
External Radio 2. This output is capable of adjustment from
2.5Vrms ±0.25 Vrms (10mW) to 7.75 Vrms ±0.25 Vrms
(100mW) into a 600 Ω load (except as noted)
46
Reserved
Reserved
47
Reserved
Reserved
48, 49
Audio 2 Out Hi/Lo
These pins provide an audio output to the audio system from
Transceiver 2. Assignment of a transceiver to Audio 2 is a
programmable option, default is to the transceiver in slot 2.
This output is capable of adjustment from 2.5Vrms ±0.25 Vrms
(10mW) to 7.75 Vrms ±0.25 Vrms (100mW) into a 600 Ω load
(except as noted)
These commodities, technology or software are controlled in accordance with the United States Export Administration Regulations, Export Classification
Control Number (ECCN) EAR99. When exporting, diversion contrary to U.S. law is prohibited.
