Overview
2-4 Outback HF Radiophone
The Radiophone front panel
The front panel of the Radiophone control head (figure 2.1 on page 2-7) has the
following designations:
Item No. Item Function
1
On/Off
Switches the transceiver on or off.
2
Tx
The indicator is lit when the transceiver is
transmitting.
3
S’Call
OTC
Transmits a selective call to a selected OTC
(Telstra) station.
4
Call
Selective
Transmits either a selective call or tone call on the
selected channel.
5
USB
LSB
Selects USB or LSB mode.
6
Tune
Transmits a carrier signal so that the automatic
antenna system can be tuned.
7
Enter
Sets the transceiver to accept programmed
information.
F
