Installation
Outback HF Radiophone 3-5
Mounting the antenna
The antenna is a critical element in any communication
system. It cannot be overstressed that correct installation
of the antenna is of prime importance to the operation of
your Radiophone.
To obtain the best performance from your Radiophone, it is
important to consider the following points when installing
your antenna:
• physical location
• distance from the transceiver
• earthing.
Detailed and specific installation instructions are provided
with the automatic tuning whip antenna. These instructions
must be used to gain the best possible results from your
antenna and transceiver.
q
Mounting the loudspeaker
The loudspeaker must be mounted in a position that will
not cause injury to occupants in the event of a motor
vehicle accident.
Step Action
1.
Mount the speaker bracket securely to a suitable surface.
2.
Connect the appropriate cable between the loudspeaker and
the control head or transceiver.
q
