Front and rear panel sock
ets
Outback HF
Radiophone
13-
3
External alarm socket
This socket is located on the rear panel of
the transceiver.
This facility allows
an external alarm device to be connected to the Radiop
hone.
When a selective call is detected, internal relay
contacts close across pins 2 &
3.
The contacts are rated for 1A at 50V DC
.
Pin No.
Designation
Pin No.
D
esignation
1
Not used
3
Relay cont
act
2
Not used
4
Ground
q
181
