Using sele
ctive call
Outback HF
Radiophone
5-5
Setting the pre-amble time period
1.
Ensure y
our
Radiophon
e is
switched off.
2.
Hold down
Call
Selective
and press
On/Off
Hold the Selective Call
button
down
for
approxim
ately t
hree
seconds.
This turns the
Radiophon
e on and in
to
the preamble set-
up
mode.
3.
Press any of the
numeric buttons
to set the
preamble leng
th.
or
Pressing any of the
numeric buttons
alternates between
a long
or short pream
ble.
4.
Press
Enter
Once enter has been
pressed, the pre-
amble
time has been set an
d can
only
be changed by
repeating this procedure.
F
Step
Action…
Display shows…
Remark
s…
56
58
