Overview
2-8
Outback HF Radiophone
The transceiver and control head rear panels
The transceiv
er and control h
ead rear panels (f
igures 2.2 an
d 2.3 on page 2-
9) show
the following items:
Item No.
Item
Function
1
Antenna sock
et.
2
Earth (groun
d) screw.
3
Automatic antenna control socket.
4
12V DC pow
er lead.
5
External 8 ohm
loudspeaker sock
et.
6
Remote control unit socket.
7
External alarm
socket.
q
17
19
