Contents
vi Outback HF Radiophone
List of drawings
Figure Title Page
2.1
The control head front panel.....................................................2-7
2.2
The transceiver rear panel.........................................................2-9
2.3
The control head rear panel.......................................................2-9
3.1
Typical vehicle installation.......................................................3-1
9.1
Telephone interconnect block diagram.....................................9-1
11.1
The control head link..............................................................11-2
11.2
The microprocessor link .........................................................11-4
