DM72, DM152 or DM262 + 6.2 mm Lens
Long Range (Focused to 190 mm)
The following tables show the FoV widths of the 6.2 mm lens focused to 190 mm at various distances.
DM150 or DM260
Distances in mm 2D min. code 1D min. code
150 12 MIL 6 MIL
190 15 MIL 10 MIL
225 18 MIL 10 MIL
375 30 MIL 15 MIL
500 35 MIL 20 MIL
1 m - 35MIL
DM152 or DM262
Distances in mm 2D min. code 1D min. code
150 10 MIL 5 MIL
190 12 MIL 6 MIL
225 15 MIL 6 MIL
375 20 MIL 10 MIL
500 25 MIL 15 MIL
1 m - 30MIL
127
Optics and Lighting
