Device Distances in mm / 1Dmin code
16 mm HSLL
Distances in mm / 2Dmin code
16 mm HSLL
DM47x
676 6 MIL 465 6 MIL
901 8 MIL 620 8 MIL
1125 10 MIL 774 10 MIL
1462 13 MIL 1006 13 MIL
1687 15 MIL 1160 15 MIL
2249 20 MIL 1547 20 MIL
Reading Distance and Field of View for DataMan 470 Series Readers with a
24 mm High-Speed Liquid Lens
Note: Due to tolerances, ranges can vary by +/- 5 % from unit to unit.
The following map shows the FoV of the DataMan 470 series readers with a 24 mm high-speed liquid lens.
144
Optics and Lighting
