5-32 Removal and Replacement Procedures - Desktop
5.16.2 5.25-Inch Drive Bays
The 5.25-inch drive bays may be occupied by diskette drives, hard drives, CD-ROM drives, PD-CD
drives, LS-120 drives, or tape drives. Removal of a CD-ROM drive is shown.
CAUTION:
All removable media should be taken out of the drives before removing the drive from the
computer.
1. Remove the system unit cover (Section 5.6).
2. Remove the front bezel (Section 5.14.1).
3. Disconnect the cables from the back of the drive.
Figure 5-30.
Disconnecting the Power
1
, the Signal
2
, and the Audio
3
Cables from a CD-ROM Drive
and an Optional Audio Board
