External Cabling
The following figure shows the locations of the external connectors on the back
of the server.
1 2
3
4
6
7
1112
10 9 8
5
Figure 7-3. External connectors
Table 7-1
External Connectors
1
Parallel port connector
7
Hot-plug power supply
2
External SCSI connector
8
Power supply outlet
3
Serial A connector
9
Mouse connector
4
Video connector
:
Keyboard connector
5
SCSI knockouts
;
Serial B connector
6
NIC (RJ-45 connector)
<
Redundant power supply bay
