6-12
Integrated Management Display
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: G-CH06.DOC Last Saved On: 2/8/99 11:27 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
System Behavior with Error Events
After system POST, if there is an F1 error condition the IMD flashes this
message:
ESC
!ALERT!
Press Any Key
to View New
Events
LCD-013.EPS
Figure 6-5. New event message
At this point it is necessary to scroll through each screen of the event
information menu before the IMD will allow movement on to other menu
choices. The display will not allow escape out of the Unviewed Events section
until all of the information stored here has been examined.
For information on interpreting the event messages, see the Integrated
Management Log shipped with the server.
After reviewing the events, proceed with normal display operation.
