Compaq ProLiant 5500 - Accessing the Hot-Plug SCSI Drives for Wide Ultra2 SCSI Models

4-22
Installing Hardware Components
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: E-CH04.DOC Last Saved On: 2/12/99 12:18 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
0
1
2 5
4
3
Figure 4-18. SCSI ID numbers - single SCSI channel (simplex mode)
with 1.6-inch drives
Accessing the Hot-Plug SCSI Drives
for Wide Ultra2 SCSI Models
1
2
Figure 4-19. Removing a Wide Ultra2 SCSI drive
