1-12
Introduction
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: B-CH01.DOC Last Saved On: 2/8/99 10:44 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Supported Internal Drive
Configurations
For Wide-Ultra SCSI-3 models
Standard server configurations can include as many as six Smart Array
Controllers depending on the installed network operating system. The Compaq
Array Controllers can support two Compaq ProLiant Storage Systems, or one
Compaq ProLiant Storage System and up to seven 1-inch or six 1.6-inch
internal, hot-pluggable hard drives.
A maximum internal SCSI configuration, optimizing performance and storage,
could include the following:
■ One network interface controller (NIC)
■ Six Compaq Array Controllers
■ Twelve Compaq ProLiant Storage Systems
For Wide Ultra2 SCSI models
Standard server configurations can include as many as six Compaq Array
Controllers depending on the installed network operating system. The Compaq
Array Controllers can support two Compaq ProLiant Storage Systems, or one
Compaq ProLiant Storage System and up to ten 1-inch internal, hot-pluggable
hard drives.
A maximum internal SCSI configuration, optimizing performance and storage,
could include the following:
■ One network interface controller (NIC)
■ Six Compaq Array Controllers
■ Twelve Compaq ProLiant Storage Systems
