4-16
Installing Hardware Components
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: E-CH04.DOC Last Saved On: 2/12/99 12:18 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Accessing the Fans
1
2
Figure 4-13. Removing a fan
1. Disconnect cable from fan.
2. Remove fan by pressing latch
1
and pull fan up
2.
