Peripheral Board Switches
The following table defines the switch settings for the peripheral board. The
Open (off) position is the default configuration for each switch.
Table 4-4
System Configuration Switch
Switch Open (Off) Position Closed (On) Position
1. Video Enable integrated video Disable integrated video
2. Lock
Configuration
Configuration can be
changed
Configuration can not be
changed
3. Rack Mount System is tower configuration System is rack mount
configuration
4. Diskette
Override
Diskette boot is controlled by
configuration
Diskette is enabled for booting
regardless of configuration
5. Password
Enable
Power on password is
enabled
Power on password is disabled
6. Maintenance * NV RAM is valid NV RAM is invalidated,
configuration is lost
NOTE:
See the
ProLiant 5500 and 5500R Service and Maintenance Guide
for information
on the use of this switch.
