6-1
Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: G-CH06.DOC Last Saved On: 2/8/99 11:27 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Chapter 6
Integrated Management Display
The Integrated Management Display (IMD) is an integrated LCD display panel
mounted on the front of the server. It is designed for customers requiring even
greater levels of uptime and improved serviceability. The LCD panel will
display information directly at the server to assist the user in diagnosing and
servicing the server without using a keyboard and monitor.
Integrated Management
Display Features
The features of the Integrated Management Display include:
■ Flexibility - The Integrated Management Display rotates to support both
tower and rack configurations.
■ Manageability - In an environment where every second counts, it is
important to have service and administrative information at your
fingertips. Typical information includes:
❏ POST (Power-ON Self-Test) messages
❏ User-defined administrative information
❏ POST error events
❏ System information
■ Ease of Use - For enhanced server management, the Integrated
Management Display provides a 16x4 character display and four button
control panel to easily navigate through menus.
