Cabling Example
This section contains example cabling scenarios covering the two common
applications. If your planned configuration does not match one of these
examples, use the SCSI Cable Matrices in Table 8-3 and the following
examples as a guide.
Standard Cabling
Configuration Using Wide Ultra
for Removable Media
Cable Example 2 illustrates a standard cabling configuration using the Wide
Ultra for removable media as shown in Figures 8-6 and 8-7.
