1-3
Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: B-CH01.DOC Last Saved On: 2/8/99 10:44 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
■ Internal Hot-Plug Drive Bay for Wide Ultra2 SCSI models
❏ The ProLiant 5500 and 5500R internal hot-plug drive cage can be
configured with ten 1-inch drives.
For further information about media bay configuration, see
Chapter 8, “Cabling for Wide Ultra2 SCSI.”
■ Internal Removable Media Bay Area
The four ProLiant 5500 and 5500R internal removable media bays support the
following:
❏ One bay occupied by a 1.44-MB diskette drive
❏ One bay occupied by a 24 X IDE or greater CD-ROM drive
❏ Two half-height 5.25-inch drive bays
SCSI
■ Wide Ultra models have a Compaq Dual Channel Integrated Wide-Ultra
SCSI-3 controller
■ Ultra2 models have a Compaq 64-bit Dual Channel Wide Ultra2 SCSI
adapter or a Compaq Smart Array 3200 controller in a slot
Video
■ Integrated PCI Video Controller provides maximum resolution of
1280 x 1024, 256 color, non-interlaced resolution
■ 2-MB video SGRAM standard
■ Supports SVGA, VGA, and EGA graphics resolution
