System Board Switches
Your ProLiant 5500 and 5500R server has been shipped with the core
frequency switch properly set. However, you may consider changing the core
frequency switch setting when upgrading to a faster processor.
CAUTION: Data integrity may be compromised when the core
frequency settings are set higher than the actual processor core
frequency.
Table 4-2
Core Frequency Switch
Switch Core Frequency
S1 S2 S3 S4
ON ON OFF ON 400 MHz
OFF ON OFF ON 450 MHz
ON ON OFF OFF 500 MHz
OFF ON OFF OFF 550 MHz
NOTE:
The switch is open when in the OFF position and closed in the ON position.
