System Board Features
1 2 3 4 5 6 7 8 9 13 15
23
11
17
18
22 21 20 19 10 14 16 12
Figure 4-11. System board features
Table 4-1
System Board Features
Identifier Description Identifier Description
1
Shared PCI/ISA slots
i
Floppy power connector
2-5
Secondary PCI bus slots
o
Memory board connector
6,7
Primary PCI bus slots
p
Power supply signal connector
8
Peripheral board connector
a
IDE connector
9 - w
Processor power module connectors
s
System board power connectors
e-y
Processor connectors
d
Core frequency switch
u
Floppy signal connector
