8-12
Wide Ultra2 SCSI Cabling
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: I-CH08.DOC Last Saved On: 2/5/99 4:06 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Table 8-3
SCSI Hardware Device Cabling
Controller Wide Ultra2 Hot-
Plug Hard Drives
in Wide Ultra2
Hot-Plug Drive
Cage
Wide Ultra2 or
Wide Ultra Non
Hot-Plug Hard Drives
in Removable Media
Bays
4/8 DAT Drive,
12/24 DAT Drive,
SCSI CD-ROM,
20/40 DLT, and
35/70 DLT Drive
Integrated Dual
Channel Wide-
Ultra SCSI-3
Controller Port 1
or Port 2
See Note 1
Connect the
19” pt. to pt.
cable, P/N
199606-007
from Port 1 or
Port 2 to the
hot-plug
backplane.
Connect the 3-
device LVD HD68
cable, P/N 269157-
008, to Port 1 or
Port 2 connector.
Connect the 3-
device LVD HD68
cable, P/N
269157-008, to
Port 1 or Port 2
connector.
64 Bit Dual
Channel Wide
Ultra2 SCSI
Adapter
See Note 1
Connect the
19” pt. to pt.
cable, P/N
199606-007
from the HD68
controller
connector to
the hot-plug
backplane.
Connect the 3-
device LVD HD68
cable, P/N 269157-
008 to the HD68
controller.
See Note 2
Connect the 3-
device LVD HD68
cable, P/N
269157-008 to
the HD68
controller .
Connect the
68/50-pin adapter
to the device, if
necessary.
Smart Array
3200 Controller
Smart Array 221
Controller
See Note 1
Connect the
19” pt. to pt.
cable, P/N
199606-007
from the HD68
controller to the
hot plug
backplane.
Connect the 3-
device LVD HD68
cable, P/N 269157-
008 to the HD68
controller
connector.
See Note 2
Not Supported.
NOTE 1:
Wide Ultra2 transfer rates not supported on this controller.
NOTE 2:
No more than 4 Wide Ultra2 non hot-plug hard drives can be connected to one multi-
device cable.
