3-6
Rack-Mount Server Installation
For use with Pentium II Xeon and Pentium III Xeon processor-based servers only
Writer: Michele Wray Project: Compaq ProLiant 5500 and 5500R Servers Setup and Installation Guide Comments: 328470-002
File Name: D-CH03.DOC Last Saved On: 2/8/99 10:49 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Contents of the rack model server box include
■ Compaq ProLiant 5500R server
■ Cables
■ Rack mounting hardware (numbers reference Figure 3-1)
➊ One pair 26-inch slide rail assemblies
➋ One pair slide rail mounting brackets
➌ Cable management arm server bracket
➍ Cable management arm
➎ Mounting hardware
➏ Plastic rail covers (2)
➐ Cable management arm rack bracket
➑ Template to mark the rack for proper attachment of the rack
mounting brackets
■ Documentation and software
❏ Server Setup and Management Package
❏ Compaq Installing Rack Products information
❏ Important Safety Information
❏ System Reference Library
❏ Reference Information
