B-1
Appendix B. CABLE DRAWINGS
B.1 Overview
This appendix provides line details for the cables available for use with the LPOD in Standalone or 1:1 Redundancy applications. Each figure
illustrates the cable’s technical specifications – e.g., connector types used, cable labeling, wiring lists, etc.
Additionally, the tables in this appendix cross-reference cable use in LPOD Standalone applications as well as the various 1:1 Redundancy
applications illustrated in Appendix A. 1:1 REDUNDANCY.
B.2 Control and Data Cables
DESCRIPTION USED FOR:
B-1
A-1, A-3, A-11
through A-27
CA-0020526
Serial Interface Cable
(19-pin circular connector to RJ-11)
Connecting 1:1 Redundant Loop Cable ‘J1’ receptacle or Standalone LPOD ‘J6 | PS ’
receptacle to CLC-10 RJ-11 comms jack
(Cable and CLC-10 are furnished as part of optional CEFD KIT KT-0020518 )
B-2
A-2, A-3, A-11
through A-27
CA-0000352
Ethernet Interface Cable
(19-pin circular connector to <2X> RJ-45)
Connecting 1:1 Redundant Loop Cable ‘J1’ receptacle or Standalone LPOD ‘J6 | PS ’
receptacle to LPODnet Ethernet jack
(Cable and LPODnet are furnished as part of optional CEFD KIT KT-0000203 )
100’ COM Cable
(19-pin circular connector to bare end)
Connecting 1:1 Redundant Loop Cable ‘J1’ receptacle or Standalone LPOD ‘J6 | PS ’
receptacle to user-specified M&C interface
B-4
(19-pin circular connector to bare end)
B-5
A-3, A-11
through A-27
CA-0020655
Rx / Tx Redundant Loop Cable
(19-pin circular receptacle to <2X> Type ‘N’
connectors, <2X> 19-pin circular connectors)
Interconnecting 1:1 Redundancy System LPOD units, Rx / Tx switches, and user M&C
interface
B-6
A-3, A-11
through A-27
CA-0020657
Tx-only Redundant Loop Cable
(19-pin circular receptacle to <1X> Type ‘N’
connector, <2X> 19-pin circular connectors)
Interconnecting 1:1 Redundancy System LPOD units, Tx switch, and user M&C interface
