2–1
Chapter 2. SYSTEM
CONNECTIONS, INSTALLATION
AND STARTUP
2.1 Overview
This chapter summarizes the connectors provided for all necessary external connections
between the LPOD PS 1 (Figure 2-1), PS 1.5 (Figure 2-2), or PS 2 (Figure 2-3) models and other
equipment.
Basic installation and operational startup information is provided in Sect. 2.3. For a detailed
overview on the LPOD’s operability, see Chapter 4. ETHERNET-BASED REMOTE PRODUCT
MANAGEMENT or Chapter 5. SERIAL-BASED REMOTE PRODUCT MANAGEMENT (for remote
M&C commands and/or queries).
