Table A-8. Parts List for KT-0000170 LPOD PS 1 X-Band 1:1 Redundancy Kit
KT-0000170 LPOD PS 1 X-Band 1:1 Redundancy Kit (as per Figure A-18)
ITEM
QTY
CEFD PART NO.
DESCRIPTION
0
2
CA-0000348
CABLE ASSY, RF, 2 FT
0
12
HW/TW14.5HDBLK
CABLE TIE, 14.5", HEAVY DUTY, BLACK
1
4
FP-0000534
BRACKET, MOUNTING, LPOD PS 1
2
2
FP-0000542
CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS 1
3
1
FP-0000537
BRACKET, UNIVERSAL, 1:1 RDNT, LPOD PS 1
4
1
FP-0000948
WAVEGUIDE, PREFORMED SEAMLESS FLEX, X, CPRG-112, LH, 1:1, PS 1
5
1
FP-0000949
WAVEGUIDE, PREFORMED SEAMLESS FLEX, X, CPRG-112, RH, 1:1, PS 1
7
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
8
1
FP-0000645
BRACKET, SUPPORT, 1:1 RED., LPOD PS 1
12
1
HW/CAP-SS14
DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,SS,W/CHAIN & RING
20
1
SW/WG-HAGS
SWITCH, WR112G, +24V, SEALED, STANDARD THREAD, COLD TEMP RATING
21
1
FP/WG0039
CNTRC, WAVEGUIDE FP - WAVEGUIDE, TERMINATION, 250W, CPR-112
22
1
RF-0000105
RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23
6
GA/CPR112-R-F-C
GASKET, ROUND, CPR112, FULL THICKNESS, CONDUCTIVE
30
8
HW/1/4-20X1/2FH
1/4-20 x 1/2 LG FLAT HD PHILLIPS SCREW, 82°, UCUT, SS
33
10
HW-0000070
3/8-16 x 3/4 LG SCREW, HEX, FLNG, SERR, SS
34
10
HW/3/8SPRINGNUT
SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
35
2
HW/4-FLT
#4 FLAT WASHER, SS
36
2
HW/4-SPLIT
#4 SPLIT LOCK WASHER, SS
37
2
HW/4-40X1.38PH
#4-40 x 1-3/8 LG PAN HD PHILLIPS SCREW, SS
40
44
HW/8-FLT
#8 FLAT WASHER, SS
41
42
HW/8-SPLIT
#8 SPLIT LOCK WASHER, SS
42
36
HW-0000325
#8-32 x 1/2 LG SCREW, HEX HD, SS
43
6
HW-0000326
#8-32 x 5/8 LG SCREW, HEX HD, SS
44
2
HW/8-32HEXNUT
#8-32 HEX NUT, SS
45
4
HW/6-FLT
#6 FLAT WASHER, SS
46
4
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
47
4
HW/6-32X5/16P.H
#6-32 x 5/16 LG PHILLIPS SCREW
