Table A-11. Parts List for KT-0000091 LPOD PS 2 C-Band 1:1 Redundancy Kit
KT-0000091 LPOD PS 2 C-Band 1:1 Redundancy Kit (as per Figure A-25)
ITEM
QTY
CEFD PART NO.
DESCRIPTION
1
1
FP-0000552
WAVEGUIDE, C-BAND, CPR-137 G, E TO H TO FLEX, LH, 1:1, PS 2
2
1
FP-0000553
WAVEGUIDE, C-BAND, CPR-137 G, E TO H TO FLEX, RH, 1:1, PS 2
3
4
FP-0000442
BRACK, MOUNTING, HPOD-LPOD PS 2
4
2
FP-0000543
CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS 2
5
1
FP-0000626
BRACKET, RF SW, UNIVERSAL, 1:1 RED., LPOD PS 2
6
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
11
2
CA/RF0097
ASSY CABLE, ROHS CONNECTOR, CSAT-7075 OUTPUT RF, ROHS
12
1
HW/CAP-SS14
DUST COVER,RECEPTACLE,NON-SHORTING,SIZE 14,SS,W/CHAIN & RING
20
1
SW/WGS28V-137S
SWITCH, WAVEGUIDE, CPR137, +28V SEALED
212
1
FP/WG0034
PNQ, WAVEGUIDE TERMINATION, SMALL FINS
22
1
RF-0000105
RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23
4
GA/CPR-137-R-H-C
GASKET, D SHAPE, CPR-137, HALF THICKNESS, CONDUCTIVE
24
2
GA/CPR137-R-F-C
GASKET, ROUND, CPR137, FULL THICKNESS, CONDUCTIVE
25
12
HW/TW14.5HDBLK
CABLE TIE, 14.5", HEAVY DUTY, BLACK
30
10
HW/3/8SPRINGNUT
SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
31
10
HW-0000070
3/8-16 x 3/4 LG SCREW, HEX, FLNG, SERR, SS
33
2
HW/4-40X1.38PH
#4-40 x 1-3/8 LG PAN HD PHIILIPS SCREW, SS
34
2
HW/4-SPLIT
#4 SPLIT LOCK WASHER, SS
35
2
HW/4-FLT
#4 FLAT WASHER, SS
36
4
HW/6-32X5/16P.H
#6-32 x 5/16 PHILLIPS SCREW
37
4
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
38
4
HW/6-FLT
#6 FLAT WASHER, SS
39
26
HW/#10-32X1/2SH
#10-32 x 1/2 LG SOCKET HD CAP SCREW, SS
40
30
HW/#10-32X5/8SHC
#10-32 x 5/8 LG SOCKET HD CAP SCREW, SS
41
48
HW/10-SPLIT
#10 SPLIT LOCK WASHER, SS
42
48
HW/10-FLT
#10 FLAT WASHER, SS
43
8
HW/5/16-18X3/4B
5/16-18 x 3/4 LG HEX HD BOLT, SS
44
8
HW/5/16-SPLIT
5/16” SPLIT LOCK WASHER
45
8
HW/5/16-FLT
5/16” FLAT WASHER
