LPOD Outdoor Amplifier / Block Up Converter Revision 9
System Connections, Installation and Startup MN-LPOD
2–13
KT-0020524 LPOD PS 2 Single Unit Shelf Style Mounting Kit
ITEM QTY CEFD PART NO. DESCRIPTION
1 1 FP-0020545 BRACKET, MOUNTING
2 2 HW/5/16-FLT FLAT WASHER, 5/16
3 2 HW/5/16-SPLIT LOCK WASHER, SPLIT 5/16
4 2 HW/5/16-18X3/4B BOLT, HEX HEAD, 5/16-18 X 3/4 LG
5 4 HW/3/8-FLT FLAT WASHER, 3/8
6 4 HW/3/8-SPLIT LOCK WASHER, SPLIT 3/8
7 2 HW/3/8-16X1B BOLT, HEX HEAD, 3/8-16 X 1 LG
8 2 HW/3/8-16X1.25B BOLT, HEX HEAD, 3/8-18 X 1.25 LG
Figure 2-8. KT-0020524 LPOD PS 2 Single Unit Shelf Style Mounting Kit
