Comtech EF Data LPOD - Block up Converter (BUC) Input

LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Introduction MN-LPOD
1–7
1.4.7 Block Up Converter (BUC) Input
The LPOD translates an L-Band input carrier to the desired output frequency (C-, X-, or Ku-Band).
LO frequencies are as follows:
BUC C, Ku, X LO Frequencies
Band
Frequency
LO Frequency
Inverting
C-Band
5850 to 6650 MHz
4900 MHz
No
5950 to 6700 MHz
5000 MHz
No
Insat C-Band
6725 to 7025 MHz
5760 MHz
No
Ku-Band
14.00 to 14.50 GHz
13.050 GHz
No
Ku-Band-W
13.75 to 14.50 GHz
12.800 GHz
No
X-Band
7900 to 8400 MHz
6950 MHz
No
Unlike most BUCs, no DC bias voltage should be provided on the center conductor of the L-Band
coax. In addition, the LPOD is available with an internal 10 MHz reference. As, such, no 10 MHz
reference is required on the center conductor of the L-Band coax. If a reference is provided on
the coax, the internal reference will detect and lock to it.
