Table A-4. Parts List for KT-0000191 Ku-Band Rx Switch Kit, OMT-Mounted, Metric
KT-0000191 Ku-Band Rx Switch Kit (as per Figure A-10)
ITEM QTY CEFD PART NO. DESCRIPTION
10 20 HW/6-SPLIT #6 SPLIT LOCK WASHER, SS
20 4 HW/6-32X7/8SHCS #6-32 x 7/8 LG SOCKET HD CAP SCREW, SS
30 1 SW/WGS28V-75SB SWITCH, WAVEGUIDE, WR75, +28VDC, SEALED, SIDE & BOTTOM MNT
40 2 FP-0001006 WAVEGUIDE, WR-75, 90-DEG ELB, #6/M4 FLANGE CLEARANCES
50 3 HW-0000313 GASKET, WR75, FLAT, CONDUCTIVE
60 24 HW/6-FLT #6 FLAT WASHER, SS
70 8 HW/M4X25SHCS M4 x 25 LG SOCKET HEAD CAP SCREW, SS
80
7
GA/GSKTWR75HALF
GASKET, WR75, HALF THK
90 8 HW/M4X12SHCS M4 x 12 LG SOCKET HEAD CAP SCREW, SS
100
16
HW/M4FLAT
M4 FLAT WASHER, SS
110 16 HW/6-32X1/2SHCS #6-32 x 1/2 LG SOCKET HD CAP SCREW, SS
120 1 RF/TRF-KU-WR75G RF TRANSMIT REJECT, WR75, GROOVED
130 4 HW/6-32HEXNUT #6-32 HEX NUT, SS
140 1 FP/6072 PLATE, SHORTING, WR75G
150 8 HW/M4LOCK M4 SPLIT LOCK WASHER, SS
160 8 HW/M4X.07HEX M4 x .07 HEX HUT, SS
