Comtech EF Data LPOD - Redundancy System Assembly Kits

LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Appendix A MN-LPOD
A–10
A.7 Redundancy System Assembly Kits
Several kits are available from Comtech EF Data to mount and install standalone or redundant LPODs, depending on the type of unit
ordered and its operational frequency.
Refer to Chapter 2. SYSTEM CONNECTIONS, INSTALLATION AND STARTUP for the available assembly kit options for 1:1 LPOD
Standalone configurations.
The figures and tables provided in the subsections that follow illustrate the CEFD kits currently available for assembling LPOD PS 1, PS 1.5
or PS 2 1:1 Redundancy Systems. Unless otherwise noted, all 1:1 Redundancy Kit figures depict use of AC Option, Waveguide Output
LPODs.
Sect. / Product
TABLE
(Parts List)
FIGURE(S) CEFD PART NO. DESCRIPTION
A.7.1
Common
A-1 A-4 KT-0000116 Rx SPLITTER & CABLES KIT
A-2 A-5, A-6 KT-0000098 Rx SWITCH, LPOD C-BAND KIT
A-3 A-7, A-8 PL/7596-1 Rx SWITCH, LPOD Ku-BAND KIT
A-4 A-9, A-10 KT-0000191 Rx SWITCH, Ku-BAND, METRIC KIT
A.7.2
LPOD PS 1
A-5 A-11, A-12 KT-0000104 PS 1 C-BAND 1:1 KIT, MTG & CABLE, Tx SWITCH
A-6
A-13, A-14
KT-0000090
PS 1 C-BAND COAX OUTPUT1:1 KIT, MTG & CABLE, Tx SWITCH
A-7
A-15, A-16
KT-0000089
PS 1 Ku-BAND 1:1 KIT, MTG & CABLE, Tx SWITCH
A-8
A-17, A-18
KT-0000170
PS 1 X-BAND 1:1 KIT, MTG & CABLE, Tx SWITCH
A.7.3
LPOD PS 1.5
A-9
A-19 – A-21
KT-0020526
PS 1.5 C-BAND DC OPTION 1:1 KIT, MTG & CABLE, Tx SWITCH
A-10 A-22, A-23 KT-0000060 PS 1.5 Ku-BAND 1:1 KIT, MTG & CABLE, Tx SWITCH
A.7.4
LPOD PS 2
A-11 A-24, A-25
KT-0000091
PS 2 C-BAND 1:1 KIT, MTG & CABLE, Tx SWITCH
A-12 A-26, A-27 KT-0000254 PS 2 Ku-BAND 1:1 KIT, MTG & CABLE, Tx SWITCH
