Comtech EF Data LPOD - Environmental; Physical

LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Introduction MN-LPOD
1–10
1.5.4 Environmental
Temperature
Operating
Standard
-40º to 122ºF (-40º to 55ºC)
Optional
-40º to 140ºF (-40º to 60ºC)
Storage
-67º to 167ºF (-55º to 75ºC)
Humidity
100% condensing rain 2” per hour
Altitude
10,000 AMSL
Shock
Normal commercial shipping and handling
1.5.5 Physical
Weight
PS 1
17 lbs. (9.1 kg) Nominal
PS 1.5
PS 2
47 lbs (21.32 kg) Nominal
Dimensions
(excluding connectors)
See Sect. 1.6 for all
dimensional envelope
figures
PS 1
12.65 x 6.26 x 7.37 in.
(321.3 x 159 x 187.2 mm)
PS 1.5
12.78 x 6.14 x 7.05 in.
(324.6 x 156 x 179.1 mm)
PS 2
16.18 x 8.80 x 9.78 x in.
(427 x 223.5 x 248.4 mm)
Connectors
IF/RF Input
Type ‘N’ Female
RF Output
PS 1
C-Band / X-band: Type ‘N’ Female (standard), CPR137G
(optional)
Ku-Band: WR75G
PS 1.5
C-Band: CPR137G
X-Band: CPR112G
Ku-Band: WR75G
PS 2
C-Band: CPR137G
X-Band: CPR112G
Ku-Band: WR75G
LNB Bias
Type ‘N’ Female
M&C/Ethernet/
Redundancy Switches
19-pin MS style (single integrated cable assembly available,
dependent upon configuration)
