Table A-3. Parts List for PL/7596-1 LPOD Ku-Band Rx Switch Kit
PL/7596-1 LPOD Ku-Band Rx Switch Kit (as per Figure A-8)
ITEM QTY CEFD PART NO. DESCRIPTION
1 1 SW/WGS28V-75SB SWITCH, WAVEGUIDE, WR75, +28VDC, SEALED, SIDE & BOTTOM MNT
2 1 RF/TRF-KU-WR75G RF TRANSMIT REJECT, WR75, GROOVED
3 7 GA/GSKTWR75HALF GASKET, WR75, HALF THK
4 1 FP/6072 PLATE, SHORTING, WR75G
5 2 99D1483 ASSY, WAVEGUIDE WR75
6 24 HW/6-32X1/2SHCS #6-32 x 1/2 LG SOCKET HD CAP SCREW, SS
7 12 HW/6-32X7/8SHCS #6-32 x 7/8 LG SOCKET HD CAP SCREW, SS
8
28
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS
9 40 HW/6-FLT #6 FLAT WASHER, SS
10
12
HW/6-32HEXNUT
#6-32 HEX NUT, SS
11 3 HW-0000313 GASKET, WR75, FLAT, CONDUCTIVE
