Comtech EF Data LPOD - Table A-5. Parts List for KT-0000104 LPOD PS 1 1:1 Redundancy Kit

LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Appendix A MN-LPOD
A–26
Table A-5. Parts List for KT-0000104 LPOD PS 1 1:1 Redundancy Kit
KT-0000104 LPOD PS 1 C-Band 1:1 Redundancy Kit (as per Figure A-12)
ITEM
QTY
CEFD PART NO.
DESCRIPTION
1
4
FP-0000534
BRACKET, MOUNTING, LPOD PS 1
2
2
FP-0000542
CHANNEL, DUAL, UNISTRUT, 1:1 RDNT, LPOD PS 1
3
1
FP-0000537
BRACKET, UNIVERSAL, 1:1 RDNT, LPOD PS 1
5
2
FP-0000580
SPACER PLATE, RF SPLITTER / COMBINER
6
1
FP-0000645
BRACKET, SUPPORT, 1:1 RED., LPOD PS 1
10
2
CA/RF0097
CABLE ASSY, ROHS CONNECTOR, CSAT-7075 OUTPUT RF
11
1
HW/CAP-SS14
DUST COVER, RECEPTACLE W/CHAIN & RING, NON-SHORTING, SIZE 14, SS
12
2
CA/6357-2
CABLE, ROHS TX (2FT)
20
1
SW/WGS28V-137S
SWITCH, WAVEGUIDE, CPR137, +28V SEALED
21
1
FP/WG0034
PNQ, WAVEGUIDE TERMINATION, SMALL FINS
22
1
RF-0000105
RF POWER SPLITTER/COMBINER, 2-WAY, 0 DEGREES, 1-2GHZ
23
4
GA/CPR-137-R-H-C
GASKET, D SHAPE, CPR-137, HALF THICKNESS, CONDUCTIVE
24
2
FP/5683
WELDMENT, WAVEGUIDE ADAPTER CPRG137 TO N
30
8
HW/1/4-20X1/2FH
1/4-20 x 1/2 LG FH PHILLIPS SCREW, 82°, UCUT, SS
31
10
HW-0000070
3/8-16 x 3/4 LG SERR HD FLNG HEX SCREW
32
10
HW/3/8SPRINGNUT
SPRINGNUT, 3/8-16, SHORT SPRING, SS (P3300)
33
2
HW/4-40X1.38PH
#4-40 x 1-3/8 LG PHILLIPS HD SCREW, SS
34
2
HW/4-SPLIT
#4 SPLIT LOCK WASHER, SS
35
2
HW/4-FLT
#4 FLAT WASHER, SS
37
4
HW/6-32X5/16P.H
#6-32 x 5/16 LG PHILLIPS HD SCREW, SS
38
4
HW/6-SPLIT
#6 SPLIT LOCK WASHER, SS S
39
4
HW/6-FLT
#6 FLAT WASHER, SS
40
26
HW/#10-32X1/2SH
#10-32 x 1/2 LG SOCKET HD CAP SCREW
41
14
HW/#10-32X5/8SHC
#10-32 x 5/8 LG SOCKET HD CAP SCREW
42
32
HW/10-SPLIT
#10 SPLIT LOCK WASHER, SS
43
32
HW/10-FLT
#10 FLAT WASHER, SS
49
12
HW/TW14.5HDBLK
CABLE TIE, 14.5", HEAVY DUTY, BLACK
50
2
HW/8-32X1/2SHCS
#8-32 x 1/2 LG SOCKET HD CAP SCREW, SS
51
4
HW/8-FLT
#8 FLAT WASHER, SS
52
2
HW/8-SPLIT
#8 SPLIT LOCK WASHER, SS
53
2
HW/8-32HEXNUT
#8-32, HEX NUT, SS
