C.3 Cleaning the LPOD PS-1.5 Heat Sinks
Follow these steps to clean the LPOD PS-1.5 Heat Sinks:
Disconnect power from the LPOD.
2 Remove the screws from all four sides of the LPOD as needed – see Figure C-8.
A. Be sure to use an appropriate screwdriver, such as the one provided with the
LPOD, to avoid damaging the screws.
B. The length of the four screws indicated in green are longer than those
indicated elsewhere. Be sure to re-install these longer screws at the same
locations.
C. The two screws located behind the waveguide may be difficult to remove
without first removing the waveguide from the chassis.
Lift the fan shroud assembly far enough off the chassis to expose the heat sink and access the fan
power supply connections – see Figure C-9.
Disconnect each fan power supply by carefully pulling the mated connector components straight apart –
see Figure C-10.
Do not twist the mated cable connection when disconnecting the cable assemblies.
Visually inspect the the exposed LPOD heat sink, located on the top of the chassis, for any accumulated
debris or blockage that may be obstructing airflow. Use compressed air to clear and clean the heat sink
as needed – see
Figure C-11.
Be sure to blow between the heat sink fin
s to remove any foreign object
accumulation.
Reconnect each fan power supply. First, align the male and female connector’s tabs. Then, push the
connectors together until the connection locks – see Figure C-12
•
Do not twist the mated cable connections when reconnecting the fan power
supplies.
• The fan power supply cables are labeled Fan 1 and Fan 2. Make sure to connect
the chassis Fan 1 cable to the fan shroud Fan 1 cable, and the chassis Fan 2
cable to the fan shroud Fan 2 cable.
Re-install the fan shroud onto the chassis – take care to keep the fan power supply cables clear of the
fan and heat sink surfaces. Then, re-install all screws as described in Step 2, making sure to re-install
the four longer screws at their same locations.
Torque the screws to 8 ±1 inch lbs.
8 Reconnect the power source to the LPOD.
