Comtech EF Data LPOD - Summary of LPOD Specifications

LPOD Outdoor Amplifier / Block Up Converter (BUC) Revision 9
Introduction MN-LPOD
1–8
1.5 Summary of Specifications
1.5.1 Characteristics
IF Input Frequency
Note 1
RF Output Frequency
950 – 1525 MHz
5.850 – 6.425 GHz
950 – 1750 MHz
5.850 – 6.650 GHz (optional)
950 – 1825 MHz
5.850 – 6.725 GHz (optional)
965 – 1265 MHz
6.725 – 7.025 GHz
950 – 1450 MHz
7.900 – 8.400 GHz
950 – 1450 MHz
14.00 – 14.50 GHz
950 – 1750 MHz
13.75 – 14.50 GHz (optional)
Model
Psat (Typical)
P1dB (Guaranteed)
Note 2
PS1-20Ku
43 dBm (20 W)
42 dBm (16 W)
PS1-32Ku
45 dBm (32 W)
44 dBm (25 W)
PS1.5-50Ku
47 dBm (50 W)
46 dBm (40 W)
PS1.5-60Ku
48 dBm (60 W)
47 dBm (50 W)
PS1-32C,X
45 dBm (32 W)
44 dBm (25 W)
PS1-50C,X
47 dBm (50 W)
46 dBm (40 W)
PS1-60C,X
48 dBm (60 W)
47 dBm (50 W)
PS1.5-80C,X
49 dBm (80 W)
48.5 dBm (70 W)
PS1.5-110C,X
50.4 dBm (110 W)
49.5 dBm (90 W)
PS1.5 or PS2-125C,X
51 dBm (125 W)
50 dBm (100 W)
PS2-150C,X
51.8 dBm (150 W)
51 dBm (125 W)
PS2-200C,X
53 dBm (200 W)
52.5 dBm (175 W)
Notes:
1. PS 2 Models available as SSPAs only, without internal L-Band BUC (Freq RF in = Freq RF out).
2. Allow 1 dB degradation from 13.75 to 14.0 GHz and 6425 to 6725 MHz.
Gain Min (Typical)
70 (75dB)
Input Power Supply Requirements
90-264 VAC, 47-63 Hz, Power Factor Corrected, .96 (typical)
(48 VDC optional)
Max IF Input level (no damage)
+10 dBm
Gain Adjust
20 dB in 0.25 dB steps
Gain Flatness
± 1.5 dB full band (± 1.0 dB PS 2 configured as SSPA only)
± 0.30 dB per 40 MHz
Gain variation over temp
±1.5 dB max, -40 to +55 °C (±1.25 dB, -40 to +60 °C)
Input Return Loss
15 dB (19.1 dB PS 2 configured as SSPA only)
Output Return Loss
19.1 dB (1.25:1 VSWR)
Noise Figure
10-15 dB typical, 20 dB max @ min. attenuation (8 dB typical,
15 dB max PS 2 configured
RF Mute Isolation
-60 dBc min
AM/PM Conversion
2° typ., 3.5° max. @ Rated P1dB output power
Third-order Intermodulation Level
(2 tones, @ -3 dB Total Backoff from P1 dB
(-6 dBc SCL), Δ 1MHz)
-30 dBc typ., -25 dBc Guaranteed
