LPOD Outdoor Amplifier / Block Up Converter Revision 9
Ethernet-based Remote Product Management MN-LPOD
4–2
4.2 Ethernet Management Interface Protocols
The user PC facilitates access to Ethernet-based remote monitor and control (M&C) of the LPOD
100BaseT/10BaseTx Ethernet Management Interface through three separately operated
protocols:
• Simple Network Management Protocol (SNMP). This requires a user-supplied Network
Management System (NMS) and a user-supplied Management Information Base (MIB)
File Browser.
• Telnet Interface. This requires use of the user PC’s Command-line interface, or a user-
supplied terminal emulation program such as HyperTerminal.
• Web Server (HTTP) Interface. This requires a compatible user-supplied web browser
such as Internet Explorer.
4.3 SNMP Interface
The Simple Network Management Protocol (SNMP) is an Internet-standard protocol for managing
devices on IP networks. An SNMP-managed network consists of three key components:
• The managed device. This includes the LPOD.
• The SNMP Agent. The software that runs on the LPOD. The LPOD SNMP Agent supports
both SNMPv1 and SNMPv2c.
• The user-supplied Network Management System (NMS). The software that runs on the
manager.
4.3.1 Management Information Base (MIB) Files
An MIB file is used for SNMP remote management of a unique device, and consist of a tree of
nodes called Object Identifiers (OIDs). Each OID provides remote management of a particular
function. These MIB files should be compiled in a user-supplied MIB Browser or SNMP Network
Monitoring System server.
The following MIB files are associated with the LPOD:
MIB File/Name (where
‘x’ is revision letter)
Description
ComtechEFData Root
MIB file
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data LPOD products (PSx) and
consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
