Control Techniques COMMANDER SE User Manual

148 Commander SE Advanced User Guide
Issue Number: 4
Table 9-1 Commander SE braking resistor values
*Based on the recommended braking resistor value
Drive
Minimum
resistance (Ω)
Recommended
resistance (Ω)
Resistor peak
power rating (W)*
SE2D200075 50 100 1.8
SE2D200110 50 100 1.8
SE2D200150 50 75 2.4
SE2D200220 40 50 3.5
SE23200400 30 30 5.9
SE23400075 100 200 3.4
SE23400110 100 200 3.4
SE23400150 100 200 3.4
SE23400220 75 100 6.9
SE23400300 75 100 6.9
SE23400400 75 100 6.9
SE33200550 12 15 11.8
SE33200750 12 15 11.8
SE33400550 39 50 13.8
SE33400750 39 50 13.8
SE43401100 24 40 17.2
SE43401500 24 30 23
SE43401850 24 24 28.7
SE53402200 10 20 34.5
SE53403000 10 12 57.5
SE53403700 10 12 57.5
