102 Commander SE Advanced User Guide
Issue Number: 4
3.15 Menu 21: Second motor map
Parameter Range Type Default Setting Update Rate
21.01 Motor 2 maximum speed clamp 0 ~ 1000.0 Hz RW Uni
EUR> 50.0
USA> 60.0
B
21.02 Motor 2 minimum speed clamp 0 ~ P21.01 Hz RW Uni 0.0 B
21.03
Motor 2 speed reference
selector
(0) A1.A2
(1) A1.Pr
(2) A2.Pr
(3) Pr
(4) Pad
(5) Prc
RW Txt
EUR> (0)A1.A2
USA> (4)Pad
L2
21.04 Motor 2 Acceleration ramp rate
0.0 ~ 3200.0
s/100Hz
RW Uni 5.0 L2
21.05 Motor 2 Deceleration ramp rate
0.0 ~ 3200.0
s/100Hz
RW Uni 10.0 L2
21.06 Motor 2 rated frequency 1000.0 Hz RW Uni
EUR> 50.0
USA> 60.0
BS, MC
21.07 Motor 2 motor rated current 0 ~ Drive rating RW Uni Drive rating BS, MC
21.08
Motor 2 motor rated full load
rpm
0 ~ 9999rpm RW Uni
EUR> 1500
USA> 1800
BS, MC
21.09 Motor 2 motor rated voltage
400V unit =
0 ~ 480V
200V unit =
0 ~ 240V
RW Uni
EUR>
400V unit =400V
200V unit =230V
USA>
400V unit =460V
200V unit =230V
BF, MC
21.10 Motor 2 rated power factor 0 ~ 1.00 RW Uni 0.85 BS, MC
21.11 Motor 2 number of poles
Auto
2P ~ 8P(0-4)
RW Uni Txt Auto (0) BS, MC
21.12 Motor 2 stator resistance 0 ~ 99.99Ω RW Uni P 0.0 BS, MC
21.13 Motor 2 voltage offset 0 ~ 25.5V RW Uni P BF, MC
21.14 Motor 2 leakage inductance 000.0 ~ 500.0mH RO Uni P A
21.15 Motor map 2 active 0 ~ 1 RO Bit P 0 B
