Commander SE Advanced User Guide 187
Issue Number: 4
12.25 Quickey Compatibility
Due to different versions of Drive user interface software, it is possible to get a compatibility issue when using the Quickey to
clone parameter set-ups between drives. This compatibility issue will cause the drive to trip on C.dat.
The following table gives the compatibility between different versions of drive user interface software:
NO: The Quickey cannot clone between these two versions of drive software
YES: The Quickey can clone between these two versions of drive software
*V02.00.04 is only used on Commander SE Size 5.
12.26 Controlling the Commander SE via the Universal Keypad
Example 1
This set up uses the UP and DOWN buttons on the Universal Keypad to control the speed of the motor: UP to increase the
speed and DOWN to decrease the speed.
The Enable/Stop/Start/Forward/Reverse control is from the drives terminals and not the Universal Keypad buttons.
Keypad top line display set up
Keypad bottom line display set up
Keypad buttons set up
Drive parameters set up
Perform a save routine: xx.00 = 1000 and press the red Stop / Reset button on the drive.
Perform a Universal Keypad save routine: 99.00 = 1000 and press the red Stop / Reset button on the keypad.
Software V01.02.01 V01.03.00 V01.05.00 V01.07.00 V01.08.00 V01.09.01 V01.10.00 V02.00.01 V02.00.04*
V01.02.01
NO NO NO NO NO NO NO NO
V01.03.00 NO
YES NO NO NO NO NO NO
V01.05.00 NO YES
NO NO NO NO NO NO
V01.07.00 NO NO NO
YES YES YES YES YES
V01.08.00 NO NO NO YES
YES YES YES YES
V01.09.01 NO NO NO YES YES
YES YES YES
V01.10.00 NO NO NO YES YES YES
YES YES
V02.00.01 NO NO NO YES YES YES YES
YES
V02.00.04* NO NO NO YES YES YES YES
YES
Parameter Description Value
99.16 HMI 2 source address 11
99.17 HMI 2 source parameter 1.21
99.20 HMI 2 text Speed reference
99.41 HMI 2 increment 100
99.42 HMI 2 upper limit 50,000
99.43 HMI 2 lower limit 0
Parameter Description Value
99.09 HMI 1 source address 11
99.10 HMI 1 source parameter 4.01
99.13 HMI 1 text Motor I
Parameter Description Value
99.05 Keypad control buttons Disable
Parameter Description Value
00.05 Speed reference selector Pr
6.43 Control word enable 0
