Commander SE Advanced User Guide 17
Issue Number: 4
3 Menus
The following table gives a list of level 1 and level 2 parameters and their corresponding extended menu parameter(s).
* Only becomes active when parameter 29 is set to “br.Eu” or “br.US” and the STOP/RESET button is pressed for 1 second.
Par Description
Default Corresponding
extended menu
parameter
Level 1 and 2
setting
Update
rate
EUR USA
LEVEL 1
01 Min. speed (Hz) 0.0 1.07 B
02 Max. speed (Hz) 50.0 60.0 1.06 B
03 Accel. rate (s/100Hz) 5.0 2.11 L2
04 Decel. rate (s/100Hz) 10.0 2.21 L2
05 Ref. select A1.A2 PAd 1.14 L2
06 Motor rated current (A) Drive rating 5.07 BS, MC
07 Motor rated speed (rpm) 1500 1800 5.08 BS, MC
08 Motor rated voltage (V) 230 / 400 230 / 460 5.09 BF, MC
09 Motor power factor 0.85 5.10 BF, MC
10 Parameter access L1 L1 11.44 B
LEVEL 2
11 Preset 1 (Hz) 0.0 1.21 L2
12 Preset 2 (Hz) 0.0 1.22 L2
13 Preset 3 (Hz) 0.0 1.23 L2
14 Preset 4 (Hz) 0.0 1.24 L2
15 Jog. speed (Hz) 1.5 1.05 L2
16 Current mode (mA) 4-.20 7.11 L2
17 Enable negative preset speeds OFF 1.10 B
18 Last trip -- 10.20 B
19 Trip before parameter 18 -- 10.21 B
20 Trip before parameter 19 -- 10.22 B
21 Trip before parameter 20 -- 10.23 B
22 Load display units Ld 4.21 B
23 Speed display units Fr 5.34 B
24 Customer scaling 1.00 11.21 B
25 Security setup 0 11.30 B
26 Fwd/rev key enable OFF 6.13 L1
27 Power up key. ref 0 1.51 I
28 Parameter cloning no 11.42 B
29 Load defaults no 11.43 B
30 Ramp mode 1 2.04 B
31 Stopping mode 1 6.01 L1
32 Variable torque select OFF 5.13 BS, MC
33 Spinning motor select 0 6.09 B
34 Positive logic select On 8.29 I
35 Start/Stop logic select 0 6.04 B, I
36 Analog output select Fr 7.33 B
37 Switching frequency (kHz) 6 5.18 B
38 Auto tune 0 5.12 B
39 Rated frequency (Hz) 50.0 60.0 5.06 BS, MC
40 No. of poles Auto 5.11 BS, MC
41 Serial mode AnSI 11.24 BF, L1
42 Baud rate 4.8 11.25 BF
43 Serial address 1.1 11.23 BF
44 Software version -- 11.29 I
45 Fieldbus node address 0 15.03
46 Fieldbus baudrate 0 15.04
47 Fieldbus diagnostics 0 15.06
48 Voltage mode selector 3 5.14 BS,MC
49 Low frequency voltage boost 3.0 5.15 BF,MC
50 Motor thermistor select OFF 8.40 LI
*51 Zero speed threshold 1.0 3.05 B
*52 Motor current threshold 0 4.01 B
*53 Motor current threshold 0 12.05 L3
*54 Brake release delay time 0 9.09 L3
