10 EMC cable screening bracket and screening clamps
EMC Screening bracket and screening clamps kit
The EMC screening bracket and screening clamps kits provide a convenient way of connecting supply, motor and control
cable screens to ground (control cables only on size 5).
The kits will contain:
Commander SE Size 1
2 x M4 screws
4 x 11.16mm cable clips
1 x Size 1 cable screening bracket
Commander SE Size 2
2 x M4 screws
4 x 11.16mm cable clips
1 x Size 2 cable screening bracket
Commander SE Size 3
4 x M4 screws
2 x SK20 screen terminal block
2 x 11.16mm cable clips
1 x Size 3 cable screening bracket
Commander SE Size 4
4 x M4 screws
2 x SK20 screen terminal block
3 x 11.16mm cable clips
1 x Size 4 cable screening bracket
Commander SE Size 5
1 x M6 screw
2 x 11.16mm cable clips
1 x M6 nut
1 x Size 5 cable screening bracket
Screen Terminal Blocks
Included in the Size 3 and 4 kits are SK20 screen terminal blocks. They provide a very easy but more expensive method of
connecting the cable screens to the screening bracket. Each screening bracket has been design to take either the SK14 or
both the SK14 and SK20 screen terminal blocks.
Commander SE Size 1:
5 x SK14 screen terminal blocks
Commander SE Size 2:
4 x SK14 screen terminal blocks
Commander SE Size 3:
3 x SK14 screen terminal blocks
2 x SK20 screen terminal blocks
Commander SE Size 4:
3 x SK14 screen terminal blocks
2 x SK20 screen terminal blocks
Commander SE Size 5:
2 x SK14 screen terminal blocks
These screening terminal blocks will take any diameter of cable up to the maximum of:
SK14 14mm diameter cable
SK20 20mm diameter cable
If these screen terminal blocks are preferred as an alternative to the cable clips, they can be purchased through Phoenix
Contact.
Phoenix Contact web site: www.phoenixcon.com
Drive Size Part Number Reference Number
1 9500-0014 SE11
2 9500-0016 SE12
3 9500-0017 SE13
4 9500-0018 SE14
5 9500-0041 SE15
