Control Techniques COMMANDER SE User Manual

Commander SE Advanced User Guide 77
Issue Number: 4
3.10 Menu10: Status and trips
Parameter Range Type Default Setting Update Rate
10.01 Drive healthy indicator 0 or 1 RO Bit P
L1 (set),
B (clear)
10.02 Drive running indicator 0 or 1 RO Bit P B
10.03 At zero speed indicator 0 or 1 RO Bit P BF
10.04 At or below min. speed indicator 0 or 1 RO Bit P BF
10.05 Below at speed window indicator 0 or 1 RO Bit P BF
10.06 At speed indicator 0 or 1 RO Bit P BF
10.07 Above at speed window indicator 0 or 1 RO Bit P BF
10.08 At 100% load indicator 0 or 1 RO Bit P B
10.09 Current limit active indicator 0 or 1 RO Bit P B
10.10 Motor regenerating indicator 0 or 1 RO Bit P B
10.11 Dynamic brake active indicator 0 or 1 RO Bit P B
10.12 Dynamic brake alarm indicator 0 or 1 RO Bit P B
10.13 Direction demanded indicator 0 or 1 RO Bit P B
10.14 Direction running indicator 0 or 1 RO Bit P B
10.15 AC supply loss indicator 0 or 1 RO Bit P B
10.16 Not used
10.17 Motor current overload indicator 0 or 1 RO Bit P B
10.18 Drive temperature alarm indicator 0 or 1 RO Bit P B
10.19 General drive alarm 0 or 1 RO Bit B
10.20 Last trip 0 ~ 200 RO Txt S P B
10.21 Second last trip 0 ~ 200 RO Txt S P B
10.22 Third last trip 0 ~ 200 RO Txt S P B
10.23 Fourth last trip 0 ~ 200 RO Txt S P B
10.24 Fifth last trip 0 ~ 200 RO Txt S P B
10.25 Sixth last trip 0 ~ 200 RO Txt S P B
10.26 Seventh last trip 0 ~ 200 RO Txt S P B
10.27 Eighth last trip 0 ~ 200 RO Txt S P B
10.28 Ninth last trip 0 ~ 200 RO Txt S P B
10.29 Tenth last trip 0 ~ 200 RO Txt S P B
10.30 Max full power braking time
0.0 ~ 400.0
secs
RW Uni 0 B
10.31 Max full power braking period 0.0 ~ 25.0 mins RW Uni 0 B
10.32 External trip 0 or 1 RO Bit BF
10.33 Drive reset 0 or 1 RW Bit 0 L3
10.34 No of auto-reset attempts 0 ~ 5 RW Uni 0 B
10.35 Auto-reset time delay 0.0 ~ 25.0 secs RW Uni 1.0 B
10.36
Hold drive healthy until last auto-
reset attempt
0 or 1 RW Bit 0 B
10.37 Stop drive on non important trips 0 or 1 RW Bit 0 B
10.38 User trip 0 ~ 200 RW Uni P 0 B
10.39 Braking energy overload accumulator 0.0 ~ 100.0% RO Uni P B
10.40 Status word 0 ~ 32767 RO Uni P B
