11.2 RFI Filter Data

RFI filters are available as optional extra parts where required.

Table 11-1 Commander SE Size 1

Table 11-2 Commander SE Size 2 - 200V, 26A, 1 phase

Table 11-3 Commander SE Size 2 - 200 / 400V, 16A, 3 phase

Table 11-4 Commander SE Size 2 - 200 / 400V, 16A, 3 phase

Table 11-5 Commander SE Size 2 - 200V, 26A, 3 phase

Table 11-6 Commander SE Size 3 - 200V, 30A

Table 11-7 Commander SE Size 3 - 400V, 17A

Table 11-8 Commander SE Size 4

Table 11-9 Commander SE Size 5

Used with

Filter Part

Filter Type Mounting Max motor cable length

Standard Low leakage Low cost Footprint Side m ft

SE11200025 to

SE11200075

4200-6101 Y Y 20 66

4200-6102 Y Y Y 75 246

4200-6103 Y Y Y 15 49

Used with

Filter Part

Filter Type Mounting Max motor cable length

Standard Low leakage Low cost Footprint Side m ft

SE2D200075 to

SE2D200220

4200-6201 Y Y Y 100 330

4200-6204 Y Y 50 164

4200-6205 Y Y Y 15 49

Used with

Filter Part

Filter Type Mounting Max motor cable length

Standard Low leakage Low cost Footprint Side m ft

SE2D200075 to

SE2D200220

4200-6202 Y Y Y 100 330

4200-6304 Y Y 15 49

4200-6207 Y Y Y 45 148

Used with

Filter Part

Filter Type Mounting Max motor cable length

Standard Low leakage Low cost Footprint Side m ft

SE23400075 to

SE23400400

4200-6202 Y Y Y 100 330

4200-6304 Y Y 15 49

4200-6207 Y Y Y 20 66

Used with

Filter Part

Filter Type Mounting Max motor cable length

Standard Low leakage Low cost Footprint Side m ft

SE23200400

4200-6203 Y Y Y 100 330

4200-6303 Y Y 20 66

4200-6209 Y Y Y 45 148

Used with Filter Part No

Filter Type Mounting Max motor cable length

Standard Low cost Footprint Side m ft

SE33200550 to

SE33200750

4200-6302 Y Y Y 100 330

4200-6303 Y Y 15 49

Used with Filter Part No

Filter Type Mounting Max motor cable length

Standard Low cost Footprint Side m ft

SE33400550 to

SE33400750

4200-6301 Y Y Y 100 330

4200-6304 Y Y 15 49

Used with Filter Part No

Filter Type Mounting Max motor cable length

Standard Low cost Footprint Side m ft

SE43401100 to

SE43401500

4200-6401 Y Y Y 100 330

4200-6402 Y Y 15 49

SE43401850

4200-6403 Y Y Y 100 330

4200-6404 Y Y 20 66

Used with Filter Part No

Filter Type Mounting Max motor cable length

Standard Bookcase m ft

SE53402200 4200-6116 Y Y 100 330

SE53403000 4200-6117 Y Y 100 330

SE53403700 4200-6106 Y Y 100 330
