Commander SE Advanced User Guide 99
Issue Number: 4
3.14 Menu 15: Fieldbus option parameters
The Menu 15 parameters contained within the Commander SE are generic for all fieldbus options. If they are viewed through
SE Soft, the Universal Keypad or a fieldbus option, then the following parameters will appear as Read Only: 15.01, 15.02,
15.06, 15.50. If they are viewed through a third party piece of software (e.g. Procomm), then all of Menu 15 parameters will
appear as Read Write.
Parameter Range Type Default Setting
15.01 Fieldbus ID 0 ~ 255 RW Uni 0
15.02 Fieldbus software version Vxx.yy 0 ~ 99.99 RW Uni 0
15.03 Fieldbus node address 0 ~ 255 RW Uni 0
15.04 Fieldbus baud rate 0 ~ 9 RW Uni 0
15.05 Data format / mode 0 ~ 99.99 RW Uni 0
15.06 Fieldbus diagnostic -9999 ~ 9999 RW Bi 0
15.07 Trip delay time 0 ~ 9999 RW Uni 0
15.08 Endianism 0 or 1 RW Bit 0
15.09~
15.10
Not used
15.11 Cyclic IN 1 mapping 0 ~ 96.99 RW Uni 0
15.12 Cyclic IN 2 mapping 0 ~ 96.99 RW Uni 0
15.13~
15.20
Not used
15.21 Cyclic OUT 1 mapping 0 ~ 96.99 RW Uni 0
15.22 Cyclic OUT 2 mapping 0 ~ 96.99 RW Uni 0
15.23~
15.29
Not used
15.30 Load option defaults 0 or 1 RW Bit 0
15.50 Fieldbus s/w version zz (Reserved) 0 ~ 99 RW Uni 0
